S133 Wind Turbine Generator

turbine generator

Suzlon S133 2.6 to 3 MW Platform

Suzlon introduced the 2.6 to 3.0 MW platform to unlock unviable sites and deliver improved energy yield suitable for all wind regimes.

144-1

133m rotor diameter with a swept area of more than 13,070 sq. meters

144-1

New 6 pole generator

144-1

Smart pitching and innovative control features

144-1

Large single-piece rotor blade measuring 65 meter

The S133 Advantage

Suzlon introduced the 3.0 MW platform to unlock unviable sites and deliver improved energy yield suitable for all wind regimes. The S133 is one of India’s largest wind turbine generators (WTG). This platform is extendable up to 3.0 MW depending on the site wind conditions. The prototype of S133-105m was set up in August 2019. These products are available in 2.6 MW to 3.0 MW variants and offer up to 160 meters hub heights. It delivers a 25-30% higher generation over the S120. The same has been confirmed in successful measurement and validation campaigns over the last years. The S133 with a 160 meter tower is commercially operating successfully as part of the Initial fleet since June 2022. The product range is validated and certified according to latest India Grid Code requirements.

...
OPERATING DATA

Wind class – IEC S
Rated power – 2.6 MW to 3.00 MW
Cut-in wind speed – 3.0m/s
Rated wind speed – 9.5 – 10m/s
Cut-out wind speed – 20m/s

...
ROTOR

Rotor diameter – 133m
Swept area – 13,070m2

...
GENERATOR

Frequency – 50Hz
Proven DFIG technology
Water – Air cooling

...
TOWER

Hub heights – Up to 160m
Type – Modular Hybrid
Lattice Tower

...
BLADE

(Carbon girder, Flatback and metal root inserts)

Power Curve

S144-Power-curve
